Frando Clutch Slave Cylinder 12.7mm
Founded in the 1990’s, FRANDO manufacture a range of specialist braking components, including discs, callipers and master cylinders. All FRANDO master cylinders operate on regular DOT 4 fluid.
Share:
Frando Clutch Slave Cylinder 12.7mm
$ 245.00 $ 245.00
Download Installation Guide
Frando Clutch Slave Cylinder 12.7mm
- PISTON DIAMETER 12.70mm.
- PISTON STROKE 20mm.
- PISTON REACH, END OF M8 THREAD TO CENTRE OF GROOVE IN PISTON, WHEN EXTENDED (AT REST ON CLUTCH ARM) 43mm. THIS CAN BE EXTENDED TO 50mm BY WINDING OUT THE ADJUSTER ON THE PISTON STEM.
- BANJO BOLT (M10x1.00) WITH BLEED NIPPLE (M6x1.00).
- FRAME ATTACHMENT THREAD M8x1.25 x 30mm LONG.
- PISTON STEM ADJUSTER THREAD M3x0.50 x 14mm LONG.
- MAJOR BODY OUTER DIAMETER 20mm.
- BODY LENGTH (EXC THREADED STEM) 55mm
- BLACK BODY FINISH
Out of stock
